Parameter name

Value

The diameter of the processed tires of wheel set in a circle riding, mm:

the greatest

the smallest

1250

840

2. Axle length:

the greatest

the smallest

2600±2

2020±2

3. Gauge width, mm

1435, 1520

4. Spindle speed limits, rpm

≤25

5. Limits of support feed, mm/min:

working longitudinal

working cross

accelerated longitudinal

accelerated transverse

≤80

≤80

≤2500

≤2500

6. Maximum cutting depth, mm

12

7. Feed, mm/rev

0,1 – 1,5

8. Accuracy of processing wheel set tires:

in a circle riding, mm

diameter difference, mm

surface roughness, Ra, m

0,2

0,3

≤ 20

9. Wheel measurement system

Automatic

10. Basing of cutting tools

Automatic

11. Turning mode

Automatic, manual

12. Control system

CNC

13. The duration of turning one wheel set, мин, не более

15

14. Number of operators

1

15. Main drive power, kW

75
