Machine of horizontal execution, with numerical control, consisting of one milling headstock, a movable column, a bed and a rotary device for installing and positioning the workpiece. Working movements are carried out from servomotors along three coordinate axes. Cutting tools - face mills with non-turning carbide inserts. The workpiece clamp is hydraulic, the positioning is automatic, the main drive and the feed drive are electromechanical. The machine is controlled from the control panel.



MAIN TECHNICAL SPECIFICATIONS

Parameter name	Value
Productivity (thrust bearing, 4 inclined surfaces), min det	40
Spindle speed, rpm	20…500
Working feed, mm/min	138
Main drive power, kW	11
Feed drive power (X, Y, Z), kW	3 х 2,2
Rotator power, kW	2,2
Overall dimensions (LхWхH), mm	6545х3370х3100
Weight, kg	12500
