Machine horizontal execution, it consist of 2 milling heads. Cutting tools - face mills with non-replaceable carbide inserts. The workpiece clamp is hydraulic, the positioning is manual mechanical, the main drive and feed drive is electromechanical. The control system is based on a programmable industrial controller. Machine control is carried out from push-button consoles.
|
Parameter |
Value |
|
Productivity, parts per hour |
No less 4 |
|
Spindle speed, rpm |
20…1000 |
|
Working feed, mm/min |
0,5…5000 |
|
Main drive power, kW |
2 х 5,5 |
|
Installed power, kW |
18,4 |
|
Frame clamp |
Hydraulic |
|
Overall dimensions, mm |
2600х1900х1650 |
|
Weight, kg |
4000 |
