Machine horizontal execution, it consist of 2 milling heads. Cutting tools - face mills with non-replaceable carbide inserts. The workpiece clamp is hydraulic, the positioning is manual mechanical, the main drive and feed drive is electromechanical. The control system is based on a programmable industrial controller. Machine control is carried out from push-button consoles.
Specification of the machine VF-2PB
|
Parameter |
Value |
|
Productivity, bearing box per hour |
10 |
|
Clamping of beabing box |
Hydraulic |
|
Number of milling heads |
2 |
|
Main drive |
|
|
Power, kW |
5,5 |
|
Output shaft speed, rpm |
280 |
|
Spindle |
|
|
Rotation frequency, rpm |
347 |
|
Cutter diameter, mm |
125 |
|
Feed drive |
|
|
Power, kW |
2,2 |
|
Output shaft speed, rpm |
140 |
